Smart AC EV Charger Wallbox | 7kW / 11kW / 22kW Level 2 EV Charging Station

Safe, Smart & Durable AC EV Charger for Home, Apartment, Workplace & Commercial Parking

Charge your EV conveniently at home, cut electricity bills with intelligent scheduling.

Product Overview

Our AC EV Charger (Wallbox) is Mode 3 Level 2 alternating current charging equipment, supporting single-phase 7kW/11kW and three-phase 22kW power options. Equipped with Type 2 / Type 1 charging gun, it fits 99% of global electric vehicles including Tesla, Volkswagen, BMW, BYD, Hyundai, KIA etc.

With IP65 waterproof & dustproof enclosure, multiple safety protection systems, WiFi/Bluetooth/App remote control, RFID card activation and OCPP protocol optional, it meets both residential private charging and commercial shared charging demands. Certified with CE, UKCA, TUV, CB, fully compliant with EU & North American EV charging standards.

Core Selling Points

  • Multi Power Selection

    7kW (32A Single Phase) / 11kW / 22kW (3-Phase), flexible match household & commercial power grid

  • Full Safety Protection

    Over-voltage / Under-voltage / Over-current / Short-circuit / Leakage / Lightning / Overheat / Anti-reverse connection 8-fold hardware protection

  • Smart App Control

    WiFi+Bluetooth connection, schedule off-peak charging, real-time power monitoring, charging record query, remote start/stop

  • Global Compatibility

    Type 2 (EU) / Type 1 (US) charging connector, compatible with all mainstream EV brands worldwide

  • Outdoor Durable Housing

    IP65 waterproof & dustproof, IK10 anti-impact, working temperature -20℃ ~ +60℃, stable in rain, snow & high temperature

  • Multiple Activation Modes

    RFID Card Swipe / App Scan QR / Plug&Charge / Timer Charging, easy for private & public use

  • Optional OCPP 1.6J Protocol

    Support cloud charging management system, dynamic load balancing, solar PV linkage, payment function for commercial projects

  • Easy Installation

    Wall-mounted / Floor pedestal dual installation way, compact size, simple wiring, low maintenance cost

Product Specifications



Item Standard Parameter
Product Name AC EV Charger Wallbox / AC EV Charging Station
Power Option 7kW(230V 32A Single Phase) / 11kW / 22kW(400V 32A 3-Phase)
Input Voltage AC220V-240V (Single) / AC380V-400V (Three Phase)
Charging Mode Mode 3 Level 2 AC Charging
Connector Type 2 IEC62196-2 (EU) / Type 1 SAE J1772 (US)
Cable Length 5m / 7m customizable charging cable
Protection Grade IP65 Enclosure, IK10 Impact Resistance
Cooling Mode Natural air cooling, low noise
Communication WiFi / Bluetooth / 4G / Ethernet (Optional)
Protocol Standard local control, OCPP1.6J (Commercial Optional)
Activation RFID Card, Mobile APP, QR Code, Plug & Charge
Working Temp -20℃ ~ +60℃
Certifications CE, UKCA, TUV, CB, LVD, EMC, RCD 30mA AC+6mA DC
Installation Wall mounted / Floor stand pedestal
Housing Material Flame-retardant ABS + Metal frame
Color Option Black / White / Grey / Custom color





All-Round Safety Protection

Every AC EV charger passes strict aging test before delivery, built-in multi-layer hardware safety circuit to eliminate hidden dangers during charging:
  1. Residual Current Protection: 30mA AC + 6mA DC leakage detection, auto cut off power to avoid electric shock
  2. Overheat Protection: Real-time temperature sensor, stop charging when overheat
  3. Lightning Surge Protection: Built-in lightning arrester for outdoor installation
  4. Short-circuit & Over-current Protection: Instant power cut when abnormal current occurs
  5. Anti-reverse Connection Protection: Prevent damage from wrong wiring
  6. Door Lock Interlock Protection: Charging gun locks automatically during charging, avoid accidental unplugging

Smart Intelligent Functions

  1. Off-Peak Timing Charging

    Set charging schedule via APP to charge during cheap off-peak electricity hours, greatly save household power cost.

  2. Real-time Data Monitor

    Check charging power, voltage, current, consumed kWh, charging duration on mobile phone anytime.

  3. Dynamic Load Balancing (DLB Optional)

    Automatically adjust charging current according to household total power load, avoid tripping circuit breaker when charging + home appliances work together.

  4. Solar Energy Linkage

    Match household solar PV system, prioritize self-use photovoltaic power for EV charging, realize zero-carbon charging.

  5. OTA Remote Upgrade

    Remote online firmware upgrade, continuously optimize charging algorithm and add new functions.

  6. Charging Record & Bill Statistics

    Auto save all charging records, monthly power consumption statistics for cost accounting.

Application Scenarios

家用壁挂安装
立柱商用安装
  1. Private Home / Villa

    Private garage daily charging, schedule night low-price charging, convenient and cost-saving

  2. Apartment & Residential Community

    Shared charging piles for property management, OCPP background unified management & user billing

  3. Office Building & Corporate Parking

    Employee corporate charging, support multiple chargers centralized management

  4. Shopping Mall, Hotel, Parking Lot

    Commercial public charging station, support QR code payment, unattended operation

  5. Car Dealer & EV Fleet Company

    Fleet vehicle batch charging, data statistics for corporate vehicle management

Certifications & Advantages

Certifications

CE, UKCA, TUV Rheinland, CB, LVD, EMC, RCD safety certification, fully meet EU, UK, Australia market import standards.

Factory Strength

  1. Professional EV charger manufacturer with 8+ years R&D experience
  2. Independent mold workshop, support custom logo, shell color, packaging
  3. Strict full inspection: raw material test → semi-finished aging → finished product 48h aging test
  4. Fast lead time: stock standard models ship within 3-7 days, customized orders 15-20 days
  5. 2-year warranty, lifetime technical after-sales support

FAQ

Questions: What power AC EV charger should I choose for home use?

Answer:
  • Single-phase household grid (220V): Choose 7kW / 11kW model
  • Three-phase grid (apartment/villa with 380V): Choose 22kW for faster charging

    7kW charges most EVs from 0-100% within 8-12 hours; 22kW finishes full charge in 3-5 hours.

Questions: Is the charger waterproof for outdoor wall installation?

Answer: Yes, IP65 waterproof and dustproof grade, can work normally in rainy, snowy, high temperature outdoor environment. We suggest installing under eave to extend service life.

Questions: Does this AC charger work with Tesla?

Answer: Yes, equipped with standard Type2 connector, compatible with all Tesla models with Type2 charging port. A Tesla adapter is available if needed.

Questions: Can I manage multiple chargers in one system for commercial parking?

Answer: Yes, OCPP 1.6J version supports cloud platform centralized management, including billing, access control, real-time monitoring for dozens of charging stations.
